Description
The ASUS B660M-Plus – ASUS TUF Gaming B660M-Plus WIFI D4 Intel B660 LGA 1700 Micro-ATX Motherboard with PCIe 5.0 and Thunderbolt 4 Support – is available at Computer Selection, Lamington Road, Mumbai, with a GST invoice and shipping across India.
- ASUS TUF GAMING B660M-PLUS WIFI D4 Micro-ATX motherboard is designed to support latest 12th Gen Intel CPU’s with LGA 1700 socket, Pentium Gold and Celeron Processors with B660 Intel Chipset.
- The board is built with PCIe 5.0 Ready supporting 4 x DIMM, up to 128GB DDR4 5333MHz(OC) of memory and Intel Turbo Boost Technology to push your experience to its peak.
- Enjoy extended connectivity with the next-gen technology of PCIe 5.0, Intel WIFI 6, two M.2 slots, Realtek 2.5Gb Ethernet, USB 3.2 Gen 2×2 Type-C, Thunderbolt 4 Support, Q-LED and many more features.
- Features the most comprehensive cooling options ever that are configurable via Fan Xpert 4 or the UEFI BIOS. It employs VRM heatsink, M.2 heatsink, PCH heatsink and hybrid fan headers.
- The board comes with DIY Friendly features. The Q-LED Core display produces light patterns by power LED during the Power-On Self-Test (POST) that can help users troubleshoot potential issues. It is also have a handful features like Overvoltage Protection, DRAM Overcurrent Protection and LANGuard.
| Model | ASUS TUF GAMING B660M-PLUS WIFI D4 Micro-ATX Motherboard |
| Part Number | 90MB1930-M0IAY0 |
| CPU Socket | Intel Socket LGA 1700 |
| Chipset | Intel B660 |
| CPU Support | Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
| Memory | 4 x DIMM, Max. 128GB, DDR4 5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3866(OC)/3733(OC)/ 3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II |
| On-Board Graphics support | 1 x DisplayPort Port 1 x HDMI Port |
| Expansion Slot |
Intel 12th Gen Processors: 1 x PCIe 5.0 x16 slot Intel B660 Chipset: 1 x PCIe 3.0 x16 slot (supports x4 mode) 1 x PCIe 4.0 x1 slots (supports x1 mode) |
| Ethernet | TUF LANGuard 1 x Realtek 2.5Gb Ethernet TUF LANGuard |
| Wireless & Bluetooth | Intel Wi-Fi 6 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2 |
| Storage |
Intel 12th Gen Processors: M.2_1 slot (Key M), type 2242/2260/2280 – Intel 12th Gen processors support PCIe 4.0 x4 mode Intel B660 Chipset: M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking – Supports up to 24-Bit/192 kHz playback |
| USB |
Rear USB (Total 8 ports) 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C) 4 x USB 3.2 Gen 2 ports (4 x Type-A) 1 x USB 3.2 Gen 1 port (1 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| Back Panel I/O Ports | 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C) 4 x USB 3.2 Gen 2 ports (4 x Type-A) 1 x USB 3.2 Gen 1 port (1 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Realtek 2.5Gb Ethernet port 5 x Audio jacks 1 x Optical S/PDIF out port |
| I/O Ports |
Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x AURA RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt header |
| Accessories |
Cables 2x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x M.2 Rubber Package 1 x M.2 SSD screw package 1 x TUF Gaming sticker Installation Media 1 x Support DVD Documentation 1 x TUF Certification card 1 x User manual |
| Dimensions | 24.4cm x 24.4cm Micro-ATX Form Factor |
| Warranty | 3 Years of Brand Warranty |
ASUS B660M-Plus Specifications
| Brand | ASUS |
| Model / SKU | TUF-GAMING-B660M-PLUS-WIFI-D4 |
| Category | Electronics |
Specifications are for guidance; please check the manufacturer’s website for the latest details.
Why Buy the ASUS B660M-Plus from Computer Selection?
Computer Selection has been a computer hardware store on Lamington Road, Mumbai since 2003. When you buy the ASUS B660M-Plus from us you get a genuine product, a GST tax invoice, secure packaging and tracked delivery across India.
Browse more options in our Electronics range, or contact our team for free compatibility advice before you buy. You can also find official details on the ASUS website.
ASUS B660M-Plus – Frequently Asked Questions
Which processors work with the ASUS B660M-Plus?
Processors that match the board's socket and chipset are supported. Check the manufacturer's CPU support list, or ask us to confirm before ordering.
Is the ASUS B660M-Plus genuine and brand new?
Yes. We sell genuine products sourced through authorised channels, and manufacturer warranty applies as per the brand's terms.
Do you provide a GST invoice for the ASUS B660M-Plus?
Yes. Every order includes a GST tax invoice, and business buyers can enter their GSTIN at checkout to claim input tax credit.
Do you ship across India?
Yes. Orders are securely packed and shipped with tracking to serviceable pin codes across India. You can also collect from our Lamington Road store.
